Premium Prefab Housing
Model No-BH-CT-510
Durable, affordable, and beautifully designed prefab homes. The smart housing choice for Bangladesh.
MOST POPULAR
Model No-BH-CT-510
📐 1200 sqft
🛏️ 4 Bedrooms
🚿 2 Bathrooms
🍳 1 Kitchen
Fixed Package Price
৳40,00,000
⚡ 3× Faster Than Traditional Brick
🛡️ 200+ km/h Cyclone & Quake Proof
📐 100% BNBC Code Certified
Overview (Area Details)
Official floor-wise layout dimensions and area specifications for Model No-BH-CT-510.
🏢 Ground Floor Layout
1200 sqft| Section | Area (sqft) | Dimensions |
|---|---|---|
| 🛏️Master bed | 168 | 14' × 12' |
| 🛏️Bed room 1 | 144 | 12' × 12' |
| 🛏️Bed room 2 | 144 | 12' × 12' |
| 🛏️Child bedroom | 120 | 12' × 10' |
| 🛋️Living room | 336 | 24' × 14' |
| 🍳Kitchen | 72 | 12' × 6' |
| 🚿Bath 1 | 36 | 6' × 6' |
| 🚿Bath 2 | 36 | 6' × 6' |
| 🌤️Veranda | 96 | 24' × 4' |
| 🌤️Porch | 48 | 8' × 6' |
| Ground Floor Subtotal | 1200 sqft |
Total Covered Area
Full Building Structure (1 Floor)
1200 sqft
Building Specifications
| Item | Materials |
|---|---|
| FOOTING | Precast RC footing & Tie beam with 2200 psi concrete. |
| LIGHT STEEL STRUCTURE | Column, rafter, purlin and others member made of MS steel grade SS400, strength 250 Mpa |
| GROUND FLOOR | 3’’ thickness cement concrete. |
| OUTER WALL | 2.5’’ thickness RC precast concrete panel |
| INNER WALL | 2’’ thickness RC precast concrete panel |
| DOOR | 7’x3.5’ steel frame with wooden shutter |
| TOILET & KITCHEN DOOR | 7’x2.5’ PVC frame with PVC shutter |
| WINDOW | 5’x4.5’ Thai frame, Glass shutter with Grill |
| FLOOR FINISHING | 16''x16'' Tiles |
| PAINT | Weather coat and plastic paint |
| ROOF TOP | .56mm steel industrial profile sheet |
| BATHROOM FITTING | Metal fittings |
| ELECTRIC WIRING | 3 bulb, 1 fan point, 3 power sockets in each room. BRB cable is to be used. |
Our Technology
Advantage of Steel-RC Building
Discover the benefits of our advanced steel-reinforced concrete building technology.
- ✔️ Cost-effective and Eco-friendly
- ✔️ High strength, inflexibility and high load bearing capacity
- ✔️ Pre-fabricated, easy to install and dismantle
- ✔️ Lightness, easy to transport and re-located
- ✔️ Low maintenance cost
- ✔️ Using several times and recycling
- ✔️ Increase area efficiency by 10%--20%
- ✔️ Environment friendly
- ✔️ Weather-resistant with proper coating and maintenance
- ✔️ Engineered for strong seismic performance
- ✔️ Engineered for high wind-load resistance
- ✔️ Energy saving with good thermal insulation system
- ✔️ 50~60 years’ life span
